Switch|MIKROTIK|Mikrotik netPower Lite 8P (CSS610-8P-2S+OUT)|8xRJ-45 ports|RJ-45 Ports Type Gigabit Ethernet (10/100/1000)|8xGigabit Ethernet (copper) ports quantity|2xSFP+ module slots quantity|10G support Yes|Power over Ethernet (PoE) Yes|8xPower over E

  • Produkta kods: CSS610-8P-2S+OUT
  • EAN: 4752224006936
  • Stāvoklis: Jauns
CenaSkaitsPiegāde

202.26 €

167.16 € (bez PVN 21%)

7

26.10.

Apraksts

Mikrotik netPower Lite 8P (CSS610-8P-2S+OUT)

With netPower Lite 7R switch you can forget about expensive GPON base stations and optical splitters. This switch is a part of our GPEN concept – aimed to bring the speed and versatility of fiber networking while using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to individual apartments.

With this switch you won’t have to worry about power issues, as there are many options. netPower Lite 7R has 7 reverse PoE ports. Depending on your setup, netPower can draw the necessary power even from a single client! Ethernet port 8 can power other PoE capable devices with the same voltage as applied to the unit. There is also a DC jack and a 2-pin terminal for alternative powering.

The outdoor enclosure allows you to install this switch in all kinds of environments – from damp attics to elevator shafts and different poles with hose clamps. netPower Lite 7R has a non-blocking throughput of 28 Gbps, switching capacity of 56 Gbps and forwarding rate of 41.7 Mpps.

  • 8× Gigabit Ethernet
  • 802.3af/at PoE-Out
  • 2× 10G SFP+ uplinks
  • 24–57 V DC input
  • Built-in smart battery charger
  • 120 W total PoE-Out
  • Integrated UPS switchover
  • Temperature sensor included

Šim produktam ir 12 mēnešu garantija.

Parametri

KopsavilkumsMikrotik netPower Lite 8P. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Networking standards: IEEE 802.3af, IEEE 802.3at. DC input voltage: 24 - 57 V. Power connector: Terminal block (2-pin). Power over Ethernet (PoE)
Ražotāja datu lapahttps://mikrotik.com/product/netpower_lite_ups
Vienības kastes augstums0.095
Vienības kastes garums0.4
Vienības kastes platums0.245
Pamata komutācijas RJ45 Ethernet portu skaits8
Pamata komutācijas RJ45 Ethernet portu tipsGigabit Ethernet (10/100/1000)
Gigabit Ethernet Copper pieslēgvietu skaits8
product_attr.SFP_MODULA_SLOTU_SKAITS2
product_attr.SASPRAUDNISSpaiļu bloks (2 kontakti)
Tīkla standartsIEEE 802.3af/IEEE 802.3at
10G atbalstsJā
Produkta krāsaBalts
Temperatūras sensorsJā
LED indikatoriJā
Starptautiskās aizsardzības (IP) kodsIP54
product_attr.NODROSINATA_OPERETAJSISTEMASwOS
Atmiņas tipsZibspuldze
Zibatmiņa0.064 MB
Vidējais laiks starp kļūmēm (MTBF)200000 h
product_attr.DC_IEVADES_SPRIEGUMS24 - 57 V
product_attr.STRAVAS_PATERINS_MAKS208 W
Barošana caur Ethernet (PoE)Jā
product_attr.POWER_OVER_ETHERNET_POE_PIESLEGVIETU_SKAITS8
Kopējais Power over Ethernet (PoE) budžets120 W
Darbības temperatūras amplitūda (T-T)-40 - 70 °C
Platums304 mm
Dziļums212 mm
Augstums71 mm
product_attr.ATBILSTIBAS_SERTIFIKATICE/EAC/RoHS
product_attr.VIENIBAS_APREKINATAIS_SVARS3.08 kg
product_attr.PRECES_NETO_SVARS2 kg
Vienības aprēķinātais tilpums0.01269 cubm
product_attr.VIENIBU_SKAITS_VIENA_SUTIJUMA_KASTE5
Kastes svars15.4 kg
product_attr.VIENIBAS_PLATUMS24.5 cm
product_attr.VIENIBU_SKAITS_UZ_PALETES0
Kastes augstums47 cm
product_attr.VIENIBAS_DZILUMS40 cm
Kastes dziļums50 cm
product_attr.VIENIBAS_AUGSTUMS9.5 cm
Kastes platums27 cm
NosaukumsNET SWITCH 8PORT 1000M 2SFP+/CSS610-8P-2S+OUT MIKROTIK
ModelisCSS610-8P-2S+OUT
Modeļa nosaukumsMikrotik netPower Lite 8P (CSS610-8P-2S+OUT)
